- Use the marks and number labels to determine the scaled dimension. For example, a measurement located at the third millimeter mark of a “1:5” scale would be equal to 15 millimeters. A measurement located at the first centimeter mark on a “1:100” scale would be equal to 100 centimeters or 1 meter. - Source: Internet
- Locate the scale size of the blueprints or architectural plans that you are measuring. This information is typically located in the title block at the bottom-right corner. The scale is the ratio of how small or large the drawing is compared with real size. - Source: Internet
- If you are going to be serious about drafting landscape designs for clients, you will need to know how to read and draw plans to scale. The two types of scales used in landscape architecture and design are an Architect’s Scale and an Engineer’s Scale. An architect’s scale is typically used for smaller or residential projects, when a plan needs to show things in a greater amount of detail, while an engineer’s scale is very useful for larger public parks, infrastructure projects, or general land planning purposes. - Source: Internet
- A standard architectural scale will actually have 12 different scales on it running along its 6 different sides. If you choose one side, you will notice you have a scale running left to right, and another running right to left. You will also notice that on the edge of the scale is the notation or label for the particular scale metric you are utilizing. We will start by selecting the 1/2” scale – so take a second , grab your scale, and locate your 1/2” scale. - Source: Internet
- Let’s say for our example that this line wasn’t drawing in 20 scale, but rather I mislabeled it and it actually is in 40 scale. Well if that’s true then how large would our represented line be? Well if I know the line is 3” and if 1”=40’ at 40 scale, then 3 * 40 = 120’. I can also measure the line with my 40 scale and see that it measures 120’ appropriately. - Source: Internet
- Blueprints use a ratio or scale to show that the image is smaller or larger than the actual size. The ratio is typically represented using a ratio such as “1:100” or “1:2.5” depending on the type of blueprint. A scale is also a type of ruler that uses a ratio to measure blueprints without the need for calculations. Scales exist for architects and several types of engineering, including civil and mechanical, and the ratios for each correspond with the ratios used in that particular field. - Source: Internet
- We can also measure lines that already exist on a scale drawing. For our example, if I were to be presenting a similar line that I just drew, only I was told it was at 1/4″ scale. I could measure the line with my architectural scale and see that at 1/4″ scale, it represents an 8′ long segment. - Source: Internet
- This scale runs right to left and it says 1/2” on it. What this means is that for every 1/2” of drawing on the plan, it equals 1’ in real life. And you can see this actually on the scale itself, each of the notations (1, 2, 3, and 4) equal 1/2”. - Source: Internet
